Double Wire Mesh Fence
Product Description
Double Wire Mesh Fence also called 2D welded mesh fence, twin wire mesh fence, 868 mesh fence, 656 mesh Fence, it is popular in European countries, such as Germany. Unlike traditional welded wire mesh fence, Double Wire Mesh fence are welded with two horizontal wire and one vertical wire, so it is stronger than traditional welded wire mesh fence.
Double Wire Mesh Fence with thicker double horizontal wires. This fence system provides both extreme rigidity and security, making it almost impossible for an intruder to break in. It is recommended for professional fencing of park, school, sports ground, factories, airports and military sites.
Features:
● Strength and rigidity: The fence panel have two horizontal wire, and the wire diameter is thicker than other fence system, that could provide additional strength and rigidity.
● Anti-theft: Fence fittings are designed to prevent theft, which makes it impossible for intruders to use tools to open, providing additional security for your property.
● Visibility: The mesh opening is big, so the fence protect against theft and vandalism in the meantime can monitor the external situation.
● Anti-corrosion: There are three kinds of popular surface treatment: hot dip galvanized, PVC coated, Powder coated, our workmanship is exquisite, and the coating is made of high-quality brand powder, which can guarantee that the fence will not rust for 20 years in normal environment.
● Suitable for slopes: Our fence can be adapted to any terrain, if your sites are not flat, such as slopes, it will be very easy to install if use our fence.
Double Wire Mesh Fence Panel
The width of panel is 2m-3m, the heights ranging from 600mm to 2440mm. The fence panel made of high quality low carbon steel wire, and then do the hot dipped galvanized, PVC coated or powder coated, increase the life span of fence panel.
Double Wire Mesh Fence Post
There are 2 kinds of installation manner:
1. The post are longer 500mm-800mm than the fence panel, and buried 500mm-800mm post under ground, and the pouring concrete to fix post.
2. Welded the base plate on the bottom of the post, use the expansion screws fix post on concrete base.
Specification
| Mesh Opening | Wire Diameter | Panel Width | Panel Height | Post Type | ||
| 50*100mm 50*150mm 50*200mm 55*150mm 55*200mm | 6/5/6mm 8/6/8mm | 2.0m 2.2m 2.5m 2.9m | 630mm | Round Post | Square Post | Rectangular Post |
| 830mm | 48mmOD*1.5-2mmT 60mmOD*1.5-2mmT | 50*50mm*1.5-2mmT 60*60mm*1.5-2mmT 80*80mm*1.5-2mmT | 40*60mm*1.5-2mmT 40*80mm*1.5-2mmT 60*80mm*1.5-2mmT | |||
| 1030mm | ||||||
| 1230mm | ||||||
| 1430mm | ||||||
| 1530mm | ||||||
| 1630mm | ||||||
| 1730mm | ||||||
| 1830mm | ||||||
| 1930mm | ||||||
| 2030mm | ||||||
| 2230mm | ||||||
| 2430mm | ||||||
| Surface treatment: Hot dipped galvanized, galvanized +PVC coated, galvanized+powder coated | ||||||
| Hot color: RAL 6005 green, RAL9005 black. All RAL color can be customized | ||||||
| Note: If you want other specification, we can also customized for you | ||||||
